●Optimized for constant or complex jumping loadings
●PWM speed control interface
●Linear speed regulation
●CW/CCW control
●Optional discrete power components or IMP modules
●Optional high/low BUS voltage solution
●Technology:FOC/with Hall
●PFC:Optional
●Output waveform:Pure Sinewave Tri-phase
●Protection:Over voltage/ Low voltage/ Over current/ Over temperature/ Over speed optional
| Applications | TPW Fan | Ceiling Fan | Ventilation | Mxier/Boat Propeller | Blender |
| Power | 10~40 W | 28~80 W | 80~600 W | 200~1200 W | 500~1500 W |
| Max RPM | 1350 | 390 | 3000 | 9000 | 18000 |
| Power Supply | Yes | No | |||
| Battery | Optional | N/a | Optional | N/a | |
| Solar | Optional | N/a | |||
| Technology | FOC/with Hall | ||||
| PFC | Optional | ||||
| Output waveform | Pure Sinewave Tri-phase | ||||
| Protection | Over voltage/ Low voltage/ Over current/ Over temperature/ Over speed optional | ||||
